Fab Shop Services and Equipment
WABO & AWS Certified Welders, TIG, MIG, Stick, & Oxy/Act Welding; Roll, Bend, Plasma Burn Plate
Count | Machine |
1 | High Definition Plasma 1-1/2” plate Oxy to 3” plate |
1 | Marvel 525 Saw 17” x 21” capacity |
1 | 2” – 14” Friction Saws |
1 | Accu Shear 5/8” x 12’ |
1 | Vertical Press (capacity to 150 tons) |
1 | ¼” x 6’ Wysong Plate Shear |
1 | Accur Press Brake 750T x 16’ Punch Presses 1 ton to 70 ton capacity |
16 | Welding Machines (200 amp to 650 amp; Tig, Wire & Stick) |
1 | CNC Beam Line Drill 40” x 55’ capacity |
1 | Universal Iron Bender |
1 | Horizontal Press 300 Ton |
1 | Pyramid Plate Rolls (1/4 x 48”) |
1 | Pyramid Plate Roll 8’ (1/2 x 96) |
2 | 100 amp Plasma |
9 | Overhead Crane capacity to 15 ton |
1 | Hydmech Band Saw |
1 | Pirahna Iron Worker |
4 | Hougen Magnetic Core Bore Drills |
1 | Portable Iron Worker 50 ton |
1 | ¾ capacity stud welder |
CNC Beamline
A computer controlled drilling machine for accurate drilling on beams, angles, channels, plates, flat bars, and tees. The Beamline can handle beams 40″ high by 55′ long.
Beamline equipment information
Min Drill – Diameter | ¼” (6.5 mm) | Max Speed – X Axis | 120 ft per minute |
Max. Drill – Diameter | 1-9/16” (50 mm) | Max Speed – Y Axis | 120 ft per minute |
Max Material – Thickness | Up to 10” (250 mm) | Spindle – Stroke | 13” (330 mm) max |
